Quad-Booting Thinkpad !

Another of the aphorisms by which I try to live my life is: try to have a different set of tools from everybody else; you need to have a “core set” that is the same as everyone else’s, but electing to suffer difference for its own sake does lead one away from monoculture syndrome – plus it also tends to drive a usefully different perspective from other peoples’.

So: I received last week a nice, inexpensive, adequate for those tasks for which I will want it, IBM Thinkpad R51 which I obtained with the help of my friend Ian (thanks, mate!) – the Kubrickesque black weight of which distinguishes me from colleagues who of course are all driving AMD-powered Acer Ferraris.

Shortly after unboxing it, I booted Windows XP – my first Windows system at home since 1994 – and spent the next 20 minutes making the following noises:

  • ooh?
  • urgh!
  • what?
  • click where?
  • no! no! f**k f**k f**k! don’t do that!
  • no, really, don’t do that…
  • look, i already have an internet service provider …
  • what are you doing now?
  • why are you rebooting?
  • yes, there is a wireless network; that is the correct password …
  • yes, really.
  • what?

…and so forth. This somehow-incredibly-long 20 minutes really made me appreciate my iMac.

Finally I managed to shut-off most of the annoyances, select screen optimisations for “performance”, and navigate enough of the system to defrag the disk, install Firefox, and shut it down.

Today, in-between bursts of presentation-writing, I was feeding CDROMs and DVDs into the brick, and have emerged at the other end with a Quad-Booting Laptop.

Nifty! (if you’re a geek)

In retrospect it was much easier than I feared:

I used the Sun JDS Linux / SuSE repartitioning tool to delete the recovery partition and squash the WinXP partition a little bit; then I set up the following partiton map:

# OS Size
1 Win XP 12Gb
2 Solaris 10 8Gb
3 NetBSD 2.0 4Gb
4 Extended rest of disk
5 Linux Swap 1Gb
6 FAT32 Spare 2Gb
7 FAT32 Spare 4Gb
8 Linux Root 7Gb

…temporarily masquerading the Solaris partition to be of type “Plan 9” in order to avoid any confusion or hassle during Linux installation.

Then I installed Mandrake Linux 10.1 from DVD into partitions 5 and 8, set-up LILO, and rebooted to permit a 5 minute install of NetBSD 2.0; this necessitated taking great care to not provide any bootloader names for the partitions, nor install the NetBSD bootloader at all, but aside from staying alert the installation was trivial.

Three down, one to go; I test-booted all the software, let them self-check, finishing with a Mandrake boot in which I added:

other=/dev/hda2
     label=Solaris
     table=/dev/hda
other=/dev/hda3
     label=NetBSD
     table=/dev/hda

…to /etc/lilo.conf, mirroring the chain-bootloader entry for the WinXP partition. A quick poke with fdisk reset the partition type for hda2 back to “0x82” – which annoyingly means both “Solaris”, and “Linux Swap” – and then I rebooted with the Solaris 10 DVD.

It just worked. The Solaris installer did err on the conservative side by suggesting I only wanted 256 colours on my 1024×768 display, as opposed to my desired 16 million, but that was fixable and otherwise the installation of SUNWCall went smoothly – but I won’t go so far as to say it was a particularly pleasurable user-interface experience.

The side-effect of the Solaris install was to blow-away the LILO bootloader (how rude) but a quick reboot off the Mandrake DVD in “rescue” mode fixed that, since it has a “automatically find a Mandrake partition, load the lilo.conf and rebuild the boot loader” option – very useful.

So: surprisingly, it all works, exactly as you would expect it. My laptop is fit to provide me with the X86-based operating systems capacity that I’m likely to need for work and play in the near future.

Next: to get a new Powerbook, as an upgrade for the system that lets me do what I want to do creatively…

Comments

13 responses to “Quad-Booting Thinkpad !”

  1. Stephen Usher
    re: Quad-Booting Thinkpad !

    I’ve noticed how rude Solaris x86 is. Whoever wrote the installer seems to have the same mindset as those from Redmond, as in “who would ever want any other OS on their machine than XXXXX?”

    There is one other question about Solaris x86 I’ve never worked out. Why is it that the x86 version is so gratuitously different from the SPARC version in userland? ie. The boot process after init starts is TOTALLY different and makes maintaining the OS in a mixed SPARC/x86 network a right pain as you can’t use the same scripts to do maintenance. It just seems totally potty to me.

    I guess it might go back to the days of the Sun 386i machine and the version of SunOS on there and the “backward compatibility” thing but that cuts little ice these days.

  2. alecm
    re: Quad-Booting Thinkpad !

    >There is one other question about Solaris x86 I’ve never worked out. Why is it that the x86 version is so gratuitously different from the SPARC version in userland?

    When’s the last time you used Solaris X86? I am betting “not recently” …

  3. Stephen Usher
    re: Quad-Booting Thinkpad !

    Erm, about a month ago.. Solaris 10 x86 beta 6.9

  4. alecm
    re: Quad-Booting Thinkpad !

    interesting. i’ll grab you online for a chat, later.

  5. Chris Samuel
    re: Quad-Booting Thinkpad !

    No BeOS, Plan9 or Hurd ?

    Not to mention the other BSD’s (Free, Open and DragonFly).

  6. alecm
    re: Quad-Booting Thinkpad !

    I’d *like* to try Plan9, just for the hell of it, but the oherts don’t really appeal… I suppose I am looking for “family” rather than “species” coverage…

  7. Chris Samuel
    re: Quad-Booting Thinkpad !

    I guess there’s always VMware under Linux for all those other OS’s that you can’t be bothered installing directly.. 🙂

  8. Dan Lacher
    re: Quad-Booting Thinkpad !

    Why not just get a big beefy powerbook and user VPC to run all the other OS. I have not have a chance to play with VPC myself but I would like to get my hands on it and have the ability to run an OS under OS X and just kill it if it starts acting up. I have heard that there are some odd networking issues that still exist in S10 under VPC so that is a bummer but I am sure they are going to get worked out.

    dl

  9. VectorMeson
    re: Quad-Booting Thinkpad !

    Not sure if it’s ready for prime time but xenolinux (xen.sf.net) looks like the way to go for multiple OS boxes – all running at once. It does require some adaptation of the lowest levels of the OS but linux, plan9 and some of the BSDs have been ported. Suddenly a laptop with 2G RAM seems reasonable.

  10. Dan Anderson
    Solaris partition now has a unique code, 0xBF

    Starting with Solaris 10, the Solaris partition now has a unique code, 0xBF. You can still use the old code 0x83, which is also used by Linux for the swap partition, but don’t risk the confusion (and potentional clobbering by Linux).

  11. Dan Anderson
    Use GRUB not LILO

    Use GRUB, not LILO, for the boot loader. LILO is so 1990s. GRUB doesn’t require rerunning a program after changes, allows editing of configuration during booting, and isn’t blown away by the Solaris boot loader (unlike LILO). Here’s a sample configuration stanza for Solaris:

    title Solaris rootnoverify (hd0,1) makeactive chainloader +1

  12. Chris Samuel
    re: Use GRUB not LILO

    Grub doesn’t know how to handle /boot on an LVM, so if you’re doing that then you’ll need LILO instead.

    Also I believe there are issues with Grub on AMD64 with /boot as an XFS partition.

    Chris

  13. Chris Samuel
    Xen

    Xen works really well, we’re using it at work for running multiple gatekeepers for various Globus versions as part of our Grid project (real distributed grids, not Sun marketspeak) on a single box.
